Panneau LCD à luminosité 15 "High 1500cd / m2
1. Introduction
Il s'agit d'un affichage de cristal liquide (LCD) de transistor mince (TFT) de couleur active (LCD) qui utilise le Silicon TFT amorphe comme dispositif de commutation. Il est composé d'un panneau LCD TFT, d'un système de rétroéclairage, d'un pilote de colonne et d'un circuit de pilote de ligne. Cet LCD TFT a une zone d'affichage active mesurée de 15,0 pouces avec une résolution (1024 horizontal par 768 Pixels Vertical Pixels).
2 caractéristiques
Panneau LCD TFT 15.0 ”
Système de rétroéclairage LED
Résolution prise en charge de 1024x768 pixels
Compatible avec la norme ROHS
Size |
15inch |
Resolution |
1024*768 |
Pixel Pitch (H x V) |
0.297 x 0.297mm |
Pixel Arrangement |
R.G.B. Vertical Stripe |
Display Mode |
Normally White |
Brightness(nits) |
1000-1500 |
Contrast Ratio |
800:1 |
Input Voltage | 3.3V |
View Angle(L/R/U/D) | 80/80/80/80 |
Response Time(ms) | 16ms |
Optical mode | TN |
Operating Temperature | -20-70° |
Storage Temperature | -30-80° |
Interface | LVDS/8-bit |
Lamp type | LED |
LED Life Time(Hrs) | 30,000Hours |
Active Area(mm,H*V) | 304.13*228.10 |
Outline Dimension | 326.50*253.50*12.00 |
Weight |
960g |
Support Color |
16.2M |
Optimum Viewing Direction |
6 o’clock |
Surface Treatment |
Anti-glare, Hard-Coating (3H) |
Authentication |
ROSH/UL |
Size | 15inch |
Panel item | RS150NET-N15 |
Panel type | a-Si TFT-LCD |
Display mode | IPS,Normally black,transmissive display |
Pixels | 1024*768 |
brightness | 1500cd/m2 |
Constrast Ratio | 800:1 |
View angle | 80/80/80/80 |
View area | 313.55*2378.25mm(H*V) |
Dispaly area | 304.128*228.096mm(H*V) |
Outline Size | 326.5*253.5*10mm(H*V*D) |
Signal Type | LVDS |
Working freqyency | 60Hz |
Working temperature | 0- 65.0゚C |
Storage Temperature | -20- +65.0゚C |
Backlight Type | WLED |
Display color | 16.7m |
Surface Treatment | Haze ,Hard coating(3H) |
Drive-screen Voltage | 3.3V |
Backlight Power Consumption | 13w |
Weight | 1kgs |
